Introduction

Perfect for freshwater fishermen who want CHIRP traditional sonar and CHIRP ClearV and CHIRP SideV scanning sonar, this bundle consistently displays clear and crisp fish arches with superior target separation as well as clear definition of structure below and to the side of the boat. This bundle includes a GT8HW-IH in-hull transducer, featuring high-wide CHIRP traditional sonar. The GT8HW-IH model is also an excellent choice for boats traveling at high speeds that want to maintain accurate depth readings. The GT30-TM transom mount transducer is also included and features CHIRP ClearV and CHIRP SideV scanning sonar. This transducer bundle is ideal for fiberglass hulls, with a deadrise of 0 Degree to 6 Degree, where fishermen want traditional sonar at high speeds.

Garmin 101276300 Attributes

• Mounting Location:Hull/ Transom Mount
• Number Of Pins:12-Pins GT30-TM And 8-Pin GT8HW-IH
• Depth:750 Feet For ClearVu/ 500 Feet For SideVu/ 800 Feet For Freshwater
• Power Rating:500 Watt
• Frequency Range:455 KHz For ClearVu/ 800 KHz SideVu
• Supported Angle:0 To 70 Degree Transom
• Cable Length:20 Feet

Garmin 101276300 Features & Benefits

• Featuring High-Wide CHIRP Traditional Sonar
• Excellent Choice For Boats Traveling At High Speeds That Want To Maintain Accurate Depth Readings
• Transducer Bundle Is Ideal For Fiberglass Hulls, With A Deadrise of 0 Degree To 6 Degree, Where Fishermen Want Traditional Sonar At High Speeds
• Garmin Offer Products With Essential Utility
• Limited 2 Year Warranty

Garmin 101276300 Warranties

• garmin-marine-warranty-policy.pdf

GT30-TM ClearV/SideV TM and GT8HW-IH High Wide In-Hull Transducer Bundle

Perfect for freshwater fishermen who want CHIRP traditional sonar and CHIRP ClearV and CHIRP SideV scanning sonar, this bundle consistently displays clear and crisp fish arches with superior target separation as well as clear definition of structure below and to the side of the boat. This bundle includes a GT8HW-IH in-hull transducer, featuring high-wide CHIRP traditional sonar. The GT8HW-IH model is also an excellent choice for boats traveling at high speeds that want to maintain accurate depth readings. The GT30-TM transom mount transducer is also included and features CHIRP ClearV and CHIRP SideV scanning sonar.

This transducer bundle is ideal for fiberglass hulls, with a deadrise of 0 to 6, where fishermen want traditional sonar at high speeds.

GT30-TM transducer specs:

• Frequency: ClearV/SideV CHIRP 455 kHz (425-485 kHz) & 800 kHz (790-850 kHz)
• Power: ClearV/SideV 500 W
• Beamwidth:ClearV (1.4×53 @ 455 kHz) & (0.8×30 @ 800 kHz); SideV (1.1×53 @ 455 kHz) & (0.7×30 @ 800 kHz)
• Maximum depth:ClearV: 750 ft.; SideV: 500 ft.
• Depth and Temperature
• Number of pins: 12-pin
• Cable length:20 ft.
• Supported deadrise/Transom angles: 0-70 degree transom

GT8HW-IH transducer specs

• Frequency: CHIRP High Wide (145-230 kHz)
• Power:250 W
• Beamwidth:24-16
• Maximum depth:800 ft. freshwater
• Depth only
• Number of pins: 8-pin
• Cable length:20 ft.
• Supported deadrise: 0- 6 deadrise
