Sale! Fit to a flat surface with a maximum tolerance of +/- 1mm. Fastening size at hinge section use (M6 / 1/4"). Fastening size for lower frame use 5mm CSK screw No.10 UNC 2 BA. Flat base hatches cannot be used with Trim kits or Roller shades Lower Frame (in) A
| Lower Frame (in) | Acrylic Colour | Hatch Weight (lb) | Acrylic Window Thickness (in) |
| Flat Base | Smoke Grey | 5.77 | 3/8 |
Dimensions
| Length X (in) | Width Y (in) | Height Z (in) | Radii R (in) | Hinge Length HX (in) | Hinge Width HY (in) | Cut-Out Length Flat X1 (in) | Cut-Out Width Flat Y1 (in) | Cut-Out Radii Flat R1 (in) |
| 12 3/4 | 12 3/4 | 1 9/16 | 2 15/16 | 3/16 | 5 7/16 | 10 1/16 | 10 1/16 | 1 9/16 |
Install on a flat surface with a maximum tolerance of +/- 1mm. The fastening size used on the hinge part (M6 / 1/4″). The fastening size on the lower frame uses 5mm CSK screw numbers. !!!!—-
PRODUCT ID: 1000794
SKU: NVN-1000794
CSKU: CWR-1000794
REWRITE: 1011905-lewmar-size-10-ocean-series-hatch-flat
MPN: 39610050
UPC: 743683111006
ASIN: B003BQB0XQ
WSKU: LEW39610050
SSKU:
NAME: Lewmar Size 10 Ocean Series Hatch Flat Base
PTITLE: Lewmar Size 10 Ocean Series Hatch Flat Base
TYPE: Marine Hardware -> Hatches
VENDOR: Lewmar
Google Category:
Amazon Category:
Amazon Title:
Google Title: Lewmar 39610050 Size 10 Ocean Series Hatch Flat Base
Amazon Category:
Gtags:
GSpecs:
