Sale! Fit to a flat surface with a maximum tolerance of +/- 1mm. Fastening size at hinge section use (M6 / 1/4"). Fastening size for lower frame use 5mm CSK screw No.10 UNC 2 BA. Lower Frame (in) Acrylic Colour Hatch Weight (lb) Acrylic Window Thickness (in) 1"
| Lower Frame (in) | Acrylic Colour | Hatch Weight (lb) | Acrylic Window Thickness (in) |
| 1″ Flange | Smoke Grey | 9.09 | 3/8 |
Dimensions
| Length X (in) | Width Y (in) | Height Z (in) | Radii R (in) | Hinge Length HX (in) | Hinge Width HY (in) | Cut-Out Length Flat X1 (in) | Cut-Out Width Flat Y1 (in) | Cut-Out Radii Flat R1 (in) |
| 15 3/8 | 20 1/2 | 1 9/16 | 2 15/16 | 3/16 | 13 3/16 | 12 7/8 | 18 | 1 11/16 |
LewmarFit is suitable for flat surfaces with a maximum tolerance of +/- 1mm. The fastening size used on the hinge part (M6 / 1/4″). The fastening size on the lower frame uses 5mm CSK screw numbers. !!!!—-
PRODUCT ID: 1000796
SKU: NVN-1000796
CSKU: CWR-1000796
REWRITE: 1011907-lewmar-size-30-ocean-series-hatch-flange
MPN: 39630070
UPC: 743683101885
ASIN: B005GLQM0K
WSKU: LEW39630070
SSKU:
NAME: Lewmar Size 30 Ocean Series Hatch Flange Base
